1.0570 Steel Material Equivalent Grade
1.0570 steel relatively have high tensile strength and yield, 1.0570 steel is a versatile structural grade steel type commonly used in critical aspects of construction and engineering projects. Transmission towers,Freight cars,Railway trucks,Building structures, Pipe work,Oil and gas platforms,Shipbuilding.
Chemical composition % of grade 1.0570
C |
Si |
Mn |
Ni |
P |
S |
Cr |
Mo |
Al |
- |
max 0.22 |
max 0.55 |
max 1.6 |
max 0.3 |
max 0.035 |
max 0.035 |
max 0.3 |
max 0.08 |
max 0.02 |
Cr+Mo+Ni < 0.048 |
1.0570 Material Similar steel grade equivalent steel materials:
|
Japanese |
Gemany |
British |
France |
International |
Chinese |
ASTMAISISAE |
JIS |
EN DIN |
EN BS |
EN NF |
ISO |
GB |
Grade 50 |
SPFC 590 |
S355JR |
S355JR |
S355JR |
------ |
Q345 |
1.0570 Material Specification
Round bar steel: 1mm to 3500mm
Square-shape steel: 1mm to 4000mm
Plate steel:0.1mm to 4000mm
Width: 10mm to 2500mm
We can supply any size based on the customer's requirement
1.0570 steel can be welded relatively easily to other weldable steels, a process enabled by its high tensile strength and lower carbon content.
1.0570 steel grade offers quite good cold forming capability but isn’t well suited to hardening, aside from limited heat treatment processes. If heat treatment is undertaken, factors such as furnace type, component dimensions, rate of heating and cooling should all be taken into consideration.
We are a trusted and reliable brand for our high quality and good manufacturing of 1.0570 steel .Our company has been a manufacturer and exporter of 1.0570 steel for decades, and has been sold all over the world with favorable price. As a responsible enterprise, we always stick to be your satisfying partner.
