A517 grade E- ASTM pressure vessel steel Additional Services
A517 grade E is a kind of pressure vessel steel under the standard of ASTM 517.A517 grade E steel suitable for high temperature environment.A517 Grade E is mainly for building fusion welded boilers and other pressure vessels.
A517 grade E Mechanical Property:
Grade |
Thickness |
Yield |
Tensile |
Elongation |
A517 grade E |
mm |
Min Mpa |
Mpa |
Min % |
6-65 |
690 |
795-930 |
16% |
|
65-150 |
620 |
725-930 |
14% |
A517 grade E chemical elements:
C |
Si |
Mn |
P |
S |
B |
Cr |
Mo |
Ti |
0.12-0.20 |
0.10-0.40 |
0.40-0.70 |
0.035 |
0.035 |
0.001-0.005 |
1.40-2.00 |
0.40-0.60 |
0.01-0.10 |
A517 grade E Size range:
Thickness: 6MM to 300MM,
Width: 1500mm to 4050mm,
Length: 3000mm to 15000mm
A517 grade E Additional Services:
High tension test
Low temperature impacting test
Simulated post-welded heat treatment (PWHT)
Heat treatment under Quenching and Tempering
Issued Orginal Mill test certificate under EN 10204 FORMAT 3.1/3.2
Shot blasting and Painting, Cutting and welding as per end user’s demands
Rolling under ASTM A20/A20M for Genenal requirements of pressure vessel used steel
(based on customer's needs)
