ABS Grade B, ABS Grade B Ship Steel Plate, ABS Grade B Marine Steel Plate
ABS Grade B ship steel plate is a common strength ship plate which owned the minimum yield strength at 235 MPa. The difference between ABS Grade A and ABS Grade B is the temperature of impacting test and impacting energy value.
ABS Grade B Marine Steel Plate Chemical Composition:
Chemical Composition of ABS Grade B |
|||||||
Grade |
The Element Max (%) |
||||||
C |
Si |
Mn |
P |
S |
Al |
N |
|
AB/B |
0.21 |
0.50 |
0.80 |
0.035 |
0.035 |
- |
0.02 |
ABS Grade B Marine Steel Plate Mechanical Property:
Grade |
Thickness |
Yield Strength |
Tensile Strength |
Elongation |
(mm) |
MPa (min) |
MPa |
% (min) |
|
|
|
|
|
|
ABS Grade B |
4-260 |
235 |
400-520 |
22 |
ABS Grade B Marine Steel Plate Specification:
Thickness:2mm-350mm
Width:1200mm-4200mm
Length:3000mm-12000mm
we also can cut into any sizes in our processing plants if customer requested.
Surface Treatment: Shot blasting and painting or coated
ABS Grade B Marine Steel Plate Application:
ABS (American Bureau of Shipping) Grade B Marine Steel Plate is mainly used in shipbuilding, onshore or offshore platform and other marine engineering.
Additional technical servicesfor ABS Grade B
Additional technical servicesfor ABS Grade B marine steel plate from Shanghai Katalor Enterprises which including Heat treatment, Z-test, Ultrasonic Examination, Low temperature impacting test.
ABS Grade B Ship Steel Plate is the high tensile strength steel with it's good toughness properties, higher strength, strong corrosion-resistance. We also have a high quality logistics team who make sure the fast delivery time and shipment. If you need ABS Grade B Ship Steel Plate, please contact us by email [email protected] for more information, We will give you the lowest price and best support.
