ASTM A240 Grade 316L (S31603) Stainless Steel Hot and Cold Working

Posted:2016-11-30 04:23:36

Type 316/316L is a molybdenum-containing austenitic stainless steel intended to provide improved corrosion resistance relative to Type 304/304L. 316L (S31603) Stainless Steel is used in the oil and gas and chemical industries for its cost effective corrosion resistance and ease of fabrication.

Composition ranges for 316L stainless steels


Grade

C

Mn

Si

P

S

Cr

Mo

Ni

N

316L

Min

-

-

-

-

-

16.0

2.00

10.0

-

Max

0.03

2.0

0.75

0.045

0.03

18.0

3.00

14.0

0.10

Mechanical properties of 316L stainless steels


Grade

Tensile Str
(MPa) min

Yield Str
0.2% Proof
(MPa) min

Elong
(% in 50mm) min

Hardness

Rockwell B (HR B) max

Brinell (HB) max

316L

485

170

40

95

217

Possible alternative grades to 316 stainless steel


Grade

Why it might be chosen instead of 316?

317L

Higher resistance to chlorides than 316L, but with similar resistance to stress corrosion cracking.

Applications of ASTM A240 Grade 316L:

1, Chemical processing, equipment
2, Laboratory benches and equipment
3, Rubber, plastics, pulp paper machinery
4, Pollution control equipment
5, Boat fittings, value and pump trim

Our company is located in Shanghai, it takes just 30 minutes from Pudong International Airport to our office. If you have any plan to China, welcome to visit our company! We will be waiting for you anytime. Hope to build the long term cooperation with your esteemed company! If you have any need of ASTM A240 Grade 316L (S31603) Stainless Steel , you are welcome to contact me .We are sincerely looking for your cooperation.,
