CCS DH32 shipbuilding steel has good toughness
CCS DH32 shipbuilding steel is not only the high tensile strength steel but also the hull structural steel. CCS DH32 shipbuilding steel has good toughness, higher strength, strong corrosion-resistance, good processing properties and welding properties.
CCS DH32 shipbuilding steel chemical composition:
Grade | C max | Si max | Mn | P max | S max | Als min | Ti max | Cu max | Cr max | Ni max | Mo max |
DH32 | 0.18 | 0.50 | 0.90-1.60 | 0.035 | 0.035 | 0.015 | 0.02 | 0.35 | 0.20 | 0.40 | 0.08 |
Note: Generally speaking, Ceq will be ≤ 0.40%. If the delivery condition is TMPC, the Ceq will be : ≤ 0.36% (thickness ≤ 50mm), ≤0.38% ( when the thickness >50-100).
Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.
CCS DH32 shipbuilding steel mechanical property:
Grade | Rm (MPa) | Re(MPa) min | A% min | Akv/J min | ||||||
E.T °C | Thickness (mm) | |||||||||
≤ 50 | >50-70 | >70-100 | ||||||||
L | C | L | C | L | C | |||||
DH32 | 440-570 | 315 | 22 | -20 | 31 | 22 | 38 | 26 | 46 | 31 |
CCS DH32 shipbuilding steel delivery condition :
Grade | Fine grains elements | category | The thickness of steel | |||||
≤ 12 | >12.5-20 | >20-25 | >25-35 | >35-50 | >50-100 | |||
DH32 | Nb+V or V | Plate/sheet | A(50) | N(50), CR(50), TM(50) | N(50), CR(25), TM(50) | |||
Profile steel | N(50), CR(50), TM(50), AR*(25) | - | ||||||
Al or Al+Ti | Plate/sheet | A(50) | AR*(25) | - | ||||
N(50), CR(50), TM(50) | N(50), CR(25), TM(50) | |||||||
Profile steel | A(50) | N(50), CR(50), TM(50), AR*(25) | - |
CCS DH32 shipbuilding steel is designed for shipbuilding and oil platform purpose. CCS DH32 shipbuilding steel is mainly used to contribute hull of ships and the cranes of break bulker and vessels in low temperature oceans.
