Large Stock Steel Plate LR DH36 High Strength
LR DH36 steel have been engineered to be optimal long-lived shipbuilding steels. The main applicationof LR Grade DH36 shipbuilding steel plate is building decks of ships, vessels and boats, other normal repairing works in shipyards.
LR DH36 Shipbuilding Steel Plate Chemical Composition
Grade |
C max |
Si max |
Mn |
P max |
S max |
Als min |
Ti max |
Cu max |
Cr |
Ni |
Mo |
Nb |
V |
|
DH36 |
0.18 |
0.50 |
0.90-1.60 |
0.035 |
0.035 |
0.015 |
0.02 |
0.35 |
0.20 |
0.40 |
0.08 |
0.02-0.05 |
0.05-0.10 |
Mechanical Property in Shipbuilding Steel Plate LR DH36
|
Grade |
Rm |
Re(MPa) min |
A% min |
Akv/J min |
||||||
|
E.T °C |
Thickness (mm) |
|||||||||
|
≤ 50 |
>50-70 |
>70-100 |
||||||||
|
L |
C |
L |
C |
L |
C |
|||||
|
LR/DH36 |
490-630 |
355 |
21 |
-20 |
34 |
24 |
41 |
27 |
50 |
34 |
High Strength LR DH36 Specification
Steel Standard: Lloyd’s Register (LR)
Thickness:2mm-350mm
Width:1200mm-4200mm
Length:3000mm-12000mm
We can supply any size based on customer΄s requirements.
LR DH36 Steel Payment and Delivery Details
1,Payment Item: T/T,L/C
2,Trade Terms: CIF,FOB,CFR,CNF
3,Delivery Time: 10-30days
4,Steel Services: Cutting, Painting, shot blasting, Pretreatment, and The Third Party Inspection in DNV,BV, LR, GL, ABS, CCS , CE Mark, TUV, ISO, and others in super thick steel plate.
5, Packaging Details: Standard export seaworthy packing or as required.
6,Loading Port: Shanghai ,Tianjin, Qingdao.
7,Offer Ability:5000MT/Per Month.
We are a trusted and reliable brand for our high quality and good manufacturing of LR DH36 steel .Our company has been a manufacturer and exporter of LR Grade DH36 shipbuilding steel plate for decades, and has been sold all over the world with favorable price. As a responsible enterprise, we always stick to be your satisfying partner.
