Pressure Vessel Steel European Standard EN 10028
Pressure Vessel Steel European Standard EN 10028
Standard: EN 10028
Category: boiler steel, pressure vessel steel
EN 10028 steel grades:P265GH, P295GH, 16Mo3, 13CrMo4-5, 10CrMo9-10, P275NH, P275NL1, P275NL2, P355N, P355NH, P355NL1, P355NL2, P460NH, P460NL1, P460NL2
EN 10028 P265GH, P295GH, 16Mo3, 13CrMo4-5, 10CrMo9-10,P275NL1, P275NL2, P355N, P355NH steel plates are widely used in petroleum, chemical, power station, boiler and other industries, for the production of reactors, heat exchangers, separators, spherical tanks, oil and gas tanks, liquefied gas tanks, nuclear reactor pressure shells, boiler steam drums, liquefied petroleum gas cylinders, Hydropower station high-pressure water pipes, turbine volutes and other equipment and components.
Certificate: The warranty book complies with the EN10204 3.1 TÜV standard
EN 10028 Pressure Vessel Steel Steel Plates Specification
|
Grades |
Materail No. |
Size（mm） |
Non-standard thickness |
||
|
Thickness |
Width |
Length |
|||
|
P265GH |
1.0425 |
3-250 |
1000-4000 |
14000 |
P 265 GH: 7,9,11,13, 14,17,26,28,32,42, 52,75,85,95,125 |
|
P295GH |
1.0481 |
5-120 |
1000-3500 |
12000 |
|
|
16Mo3 |
1.5415 |
2-200 |
1000-3000 |
12000 |
|
|
13CrMo4-5 |
1.7335 |
3-160 |
1000-3000 |
12000 |
P 295 GH: 13,14,18, 26,28 |
|
10CrMo9-10 |
1.7380 |
3-120 |
1000-2500 |
12000 |
|
|
P355GH |
1.0473 |
4-15 |
1000-3600 |
12000 |
|
|
P275NH |
1.0487 |
5-120 |
1000-4000 |
14000 |
|
|
P275NL1 |
1.0488 |
5-120 |
1000-4000 |
14000 |
|
|
P275NL2 |
1.1104 |
5-120 |
1000-4000 |
14000 |
|
|
P355NH |
1.0565 |
3-220 |
1000-3500 |
13000 |
|
|
P355NL1 |
1.0566 |
3-220 |
1000-3500 |
13000 |
|
|
P355NL2 |
1.1106 |
3-220 |
1000-3500 |
13000 |
|
|
P460NH |
1.8935 |
4-180 |
1000-3000 |
13000 |
|
|
P460NL1 |
1.8915 |
4-180 |
1000-3000 |
13000 |
|
|
P460NL2 |
1.8918 |
4-180 |
1000-3000 |
13000 |
|
