ABS Grade AH40,AH40 steel plate,ABS AH40 shipbuilding steel plate
ABS AH40 steel is a kind of high tensile strength marine steel. It is mainly used for making the offshore oil drilling platform, the hull of ship building and ship repairing, the platform pipe joints and other components.we have thousands tons of shipbuilding steel plate and sheet and angles and buld flats in stock which are ready to ship on board.Different thicknesses,width mainly in 2000-2500mm,length mainly in 6000-12000mm for steel plate ABS Grade AH40.
ABS Grade AH40 chemical composition in shipbuilding steel plate, angle steel bar, bulb flat bar, L section steel bar
|
Grade |
C max |
Si max |
Mn |
P max |
S max |
Als min |
Ti max |
Cu max |
Cr max |
Ni max |
Mo max |
Nb |
V |
N max |
|
AH40 |
0.18 |
0.50 |
0.90-1.60 |
0.035 |
0.035 |
0.015 |
0.02 |
0.35 |
0.20 |
0.40 |
0.08 |
0.02-0.05 |
0.05-0.10 |
|
ABS AH40 Mechanical properties
|
Grade |
Thickness |
Yield Strength |
Tensile Strength |
Elongation |
Impact Energy |
|
(mm) |
MPa (min) |
MPa |
% (min) |
(KV J) (min) |
|
|
|
|
|
|
0 degree |
|
|
ABS AH40 |
8-240 |
390 |
510-650 |
20 |
41J |
we are specialized at shipbuilding steel plate which beyond nine classification society approval.every year ,we can export more than 100000 ton steel products ,if you need any kings of ABS Grade AH40 steel plate ,please contact us for more information!
