ASTM A533GR C Pressure Vessel And Boiler Steel Plate

Posted:2014-11-30 00:25:56

ASTM A533 Grade C(A533GR C) Pressure Vessel And Boiler Steel Plate are used in Pressure Vessel,Boiler,Storage Tanks and Heat Exchanger in Oil,Gas Project..we can offer the following A533 Grade C steel plate specification:

Standard : ASTM A-533/A-533M

Steel Grade : A533 Gr A, A533 Gr B, A533 Gr C, A533 Gr D

Maximum Thickness: 300mm
Width: 1500mm to 4020mm
Length: 3000mm to 18000mm

A533 TYPE C Chemical composition % of the Product analysis of grade

Grade	C %	Mn %(<40mm)	P%	S%	Si%	Mo%	Ni%
A533 TYPE C	0.25	1.07-1.82	0.035	0.035	0.13-0.45	0.41-0.84	0.67-1.03

A533 TYPE C Mechanical Property

Grade	Min Yield	Tensile	Thicknesss	Elongation
A533 TYPE C	345 Mpa	550-690Mpa	<50MM	18%

we are specialized in producing and exporting A533/A533MA533 TYPE C NACE MR0175, MR0103 Boiler steel plate, Standard Specification for Pressure Vessel Plates, Alloy Steel,for more information please do not hesitate to contact us .
