ASME SA387 Grade 11 Class 1 Steel

ASME SA387 Grade 11 Class 1 Steel

ASME SA387 Grade 11 Class 1 material is a chromium-molybdenum alloy steel plates for welded broilers and pressure vessels designed for elevated temperature service. Katalor Industry is a ASME SA387 Grade 11 Class 1 steel plate manufacturers, delivering to the whole of the world.We are having largest inventory & ready stock of around 200 tons of SA387 Grade 11 Class 1 boiler steel, SA387 GR.12 CL.2 alloy steel and SA387 Grade 11 Class 1 pressure vessel coils, sheets, and plates in different size, grades & cuts.
Alloy Steel ASME SA387 Grade 11 Class 1 steel plates also provide excellent corrosion and oxidation resistance, which is a must in sour gas applications.ASME SA387 Grade 11 Class 1 steel sheets and plates have excellent resistance towards heat, stress-corrosion cracking and corrosive medium. ASME SA387 GR.11 CL.1 coils are easy to machine, stamp and fabricate and can be manufactured to precise tolerances.
ASME SA387 Grade 11 Class 1 Steel Products Specification
Thickness : 3-150mm
Width: 1220-4200mm
Length: 5000-18000mm
Notes: coil thickness ≤ 25mm

ASME SA387 Grade 11 Class 1 Steel Chemical Composition(%):

Grade

C

Mn

Si

P max

S

Cr

Mo

SA387 Grade 11 Class1

0.04-0.17

0.35-0.73

0.44-0.86

0.035

0.035

0.94-1.56

0.40-0.70

ASTM A387 Grade 11 Class1 Steel Mechanical Properties:

Grade

Tensile Strength(MPa)

Yield Strength(MPa) min

% Elongation in 2 in.(50mm) min

% Elongation in 8 in.(200mm) min

Impacting Test Temperature(°C)

SA387 Grade 11 Class1

415-585

240

22

19

-20,40,-60

Katalor Industry specializes in SA387 Grade 11 Class 1 steel, SA387 GR.11 CL.2 boiler steel, SA387 Grade 11 Class 11pressure vessel plates, and SA387 GR.11 CL.2 boiler steel. With 25 years of experience in manufacturing SA387 Grade 11 Class 1 pressure vessel plate we offer high quality, lower cost but the best service.
