1.5415 Steel Plate

Posted:2018-11-30 13:55:53

1.5415 material is an alloy steel formulated for primary forming into wrought products. 1.5415 is the EN numeric designation for this material. 16Mo3 is the EN chemical designation. Cited properties are appropriate for the normalized condition.

Chemical Composition(cast analysis )

Element % by mass Element % by mass

Carbon (C) 0.12 to 0.20 Silicon (Si) ≤0.35

Manganese (Mn) 0.40 to 0.90 Phosphorous (P) (max) 0.025

Sulphur (S) (max) 0.010 Nickel (Ni) ≤0.30

Nitrogen (N) ≤0.012 Chromium (Cr) ≤0.30

Copper (Cu) ≤0.30 Molybdenum (Mo) 0.25-0.35

Mechanical Properties:

Usual Delivery Condition	Thickness (mm)	Yield Strength MPa (min)	Tensile Strength MPa	Elongation % (min)	Impact Energy (KV J) (min)
Usual Delivery Condition	Thickness (mm)	Yield Strength MPa (min)	Tensile Strength MPa	Elongation % (min)	-20°	0°	+20°
Normalized	≤ 16	235	360 to 480	24	27	34	40
	16> to ≤40	225	360 to 480	24	27	34	40
	40> to ≤60	215	360 to 480	24	27	34	40
	60> to ≤100	200	360 to 480	24	27	34	40
	100> to ≤150	185	350 to 480	24	27	34	40
	150> to ≤250	170	350 to 480	24	27	34	40

1.5415 Plates Specification

Standard : AISI, ASTM, BS, DIN, GB, JIS
Thickness : 3 - 300 mm
Width : 1000 - 4000 mm
Length : 1000 -12000 mm
1.5415 Plate Processing
The normal processing can be performed on 1.5415 plates including
Cutting
Forming Drilling
Grinding
Testing
Available Grades:
P235GH
P265GH
P295GH
P355GH
16Mo3

Shanghai Katalor is located in Pudong district of Shanghai city. It is only 30 minutes from Pudong International airport to our company. If you have chance to China, we sincerely invite you to visit our factory. We have five big steel processing centers located in Shanghai City, Tianjin City, Qingdao City, Wuhan City and Nanyang City. Every processing center can process steel material 200,000 tons annually, So we have the 1.5415 plate machining capacity and offer the products processing like cutting, drilling, wedding, milling, turning, bending. We have the ability to produce every kinds of steel structural parts. If you need 1.5415 steel products, please be free to contact us.
