ASME SA204 GR.A Alloy Steel for Pressur Vessel Plate

ASME SA204 GR.A Alloy Steel for Pressur Vessel Plate

ASME SA204 GR.A material is molybdenum-alloy steel plates, intended particularly for welded boilers and other pressure vessels. ASME SA204 steel plates cited properties are appropriate for the as-fabricated (no temper or treatment) condition. It has the lowest strength and highest ductility compared to the other variants of ASME SA204 steel.
Category: alloy steel, pressure vessel steel, boiler steel
Relative grades: SA204 grade B, SA204 GR.C
Use:welded boilers and other pressure vessels
SA204 Grade A Steel Chemical Requirements

Grade

C

Mn max

P max

S max

Si

Mo

SA204 Grade A

0.18-0.25

0.98

0.025

0.025

0.13-0.45

0.41-0.64

SA204 Grade A Steel Tensile Requirements

Grade

Tensile Strength MPa(ksi)

Yield Strength MPa(ksi)

% Elongation in 8 in.(200mm) min

% Elongation in 2 in.(50mm) min

SA204 Grade A

450-585(65-85)

≥255(37)

≥19

≥23

Heat Treatment
The maximum thickness of ASME SA204 Grade A pressure vessel plates is limited only by the capacity of the composition to meet the specified mechanical property requirements, however, current practice normally limits the maximum thickness of SA204 Grade A pressure steel plates furnished under 150 mm. SA204 Grade A pressure steel Plate in 40 mm and under in thickness are normally supplied in the as-rolled condition. The ASME SA204 Grade A bolier plates shall be normalized if over 40 mm.
Katalor supply our SA204 GR.A pressure vessel plates to various countries like Egypt, Venezuela, Pakistan, Vietnam, Germany and so on, if you are interested with our goods SA204 Grade A bolier plates be free to let us know your requirements.
