ASME SA204 Grade C Alloy Steel for Pressure Vessel Plate

ASME SA204 Grade C Alloy Steel for Pressure Vessel Plate

ASME SA204 Grade C material is a kind of Mo-alloy steel material used in numerous tasks where strength, appearance, and ease of fabrication are highly required. Our wide gamut of ASME SA204 GR.C alloy steel sheet is highly demanded in the global market for its brilliant features.
SA204 Grade C Pressure Vessel Plate Specification
Category: alloy steel, pressure vessel steel, boiler steel
Relative grades: SA204 grade A, SA204 grade B
Use:welded boilers and other pressure vessels
Thickness: from 5 mm~150 mm
Width: from 1500 mm~4000 mm
Length: from 6000 mm~12000 mm
SA204 Grade C Alloy Steel Parameters
Chemical Composition(%, by weight)

Grade

C

Mn max

P max

S max

Si

Mo

SA204 Grade C

0.23-0.28

0.98

0.025

0.025

0.13-0.45

0.41-0.64

Mechanical Properties

Grade

Tensile Strength MPa(ksi)

Yield Strength MPa(ksi)

% Elongation in 8 in.(200mm) min

% Elongation in 2 in.(50mm) min

SA204 Grade C

515-655(75-95)

≥295(43)

≥16

≥20

SA204 Grade C Plates Heat Treatment

1-1/2 in. steel plates SA204 Grade C [40mm] and under in thickness are normally supplied in the as-rolled condition. The plates may be ordered normalized or stress relieved or both. The ASME SA204 Grade B alloy steel plate shall be normalized if over 40 mm.
Katalor enterprises have advanced steel processing equipment, include automatic arc-submerging welder, Dc manual arc welding machine, radial drill, CNC floor-type sharp boring machine, CNC gantry milling, cross submerged arc welding machine, H-beam assembling machine, H-beam welding production line, Box column (beam) welding production line. We can supply high quality SA204 Grade C pressure vessel plate for you, please send us inquiry If you need.
